Generating Architecture Diagrams with Mermaid.js

They say a picture is worth a thousand words, and nowhere is that more true than in software architecture and documentation. However, maintaining diagram files alongside code can be a hassle, especially when trying to version control them.

That’s why I’ve natively integrated Mermaid.js into the blog. Mermaid allows you to generate beautiful flowchart, sequence, class, state, and other diagrams directly within your Markdown files using simple, version-controllable text!

Whether you are documenting a Homelab setup, Docker architecture, Cyber Security attack path, or software design, Mermaid makes creating and updating visual representations incredibly simple.

1. Flowcharts for Infrastructure

Flowcharts are excellent for visualizing network flows, container setups, or application components. Here is a basic flowchart showing a typical homelab web request:

%%{init: {
  "theme": "base",
  "themeVariables": {
    "background":         "#0d1117",
    "mainBkg":            "#161b22",
    "primaryColor":       "#161b22",
    "primaryBorderColor": "#00d4ff",
    "primaryTextColor":   "#e6edf3",
    "lineColor":          "#00d4ff",
    "secondaryColor":     "#161b22",
    "tertiaryColor":      "#0d1117",
    "edgeLabelBackground":"#161b22",
    "nodeTextColor":      "#e6edf3",
    "fontFamily":         "ui-monospace, monospace"
  }
}}%%
graph TD;
    User((User))-->|HTTPS| Cloudflare[Cloudflare Proxy];
    Cloudflare-->|HTTPS| Traefik[Traefik Reverse Proxy];
    Traefik-->|Internal Routing| App1[CyberChef Container];
    Traefik-->|Internal Routing| App2[Nextcloud Container];
    App2-->DB[(PostgreSQL Database)];

2. Sequence Diagrams for Workflows

Sequence diagrams perfectly illustrate how different entities interact over time, making them ideal for explaining things like the OAuth PKCE flow or authentication handshakes:

%%{init: {
  "theme": "base",
  "themeVariables": {
    "background":            "#0d1117",
    "mainBkg":               "#161b22",
    "primaryColor":          "#161b22",
    "primaryBorderColor":    "#00d4ff",
    "primaryTextColor":      "#e6edf3",
    "lineColor":             "#00d4ff",
    "signalColor":           "#00d4ff",
    "signalTextColor":       "#e6edf3",
    "actorBkg":              "#161b22",
    "actorBorder":           "#00d4ff",
    "actorTextColor":        "#e6edf3",
    "actorLineColor":        "#4d9fff",
    "activationBkgColor":    "#0d1117",
    "activationBorderColor": "#00d4ff",
    "labelBoxBkgColor":      "#161b22",
    "labelBoxBorderColor":   "#00d4ff",
    "labelTextColor":        "#e6edf3",
    "noteBkgColor":          "#0d2233",
    "noteBorderColor":       "#00d4ff",
    "noteTextColor":         "#e6edf3",
    "sequenceNumberColor":   "#0d1117",
    "fontFamily":            "ui-monospace, monospace"
  }
}}%%
sequenceDiagram
    participant Client
    participant API Gateway
    participant Auth Service

    Client->>API Gateway: POST /login (Credentials)
    API Gateway->>Auth Service: Validate Credentials
    Auth Service-->>API Gateway: Valid (Issue Token)
    API Gateway-->>Client: 200 OK (JWT Token)

    Client->>API Gateway: GET /secure-endpoint (Bearer Token)
    API Gateway-->>Client: 200 OK (JSON Data)

3. Visualizing Git Branching Strategies

Explaining complex merge strategies? You can even draw Git branching histories natively:

%%{init: {
  "theme": "base",
  "themeVariables": {
    "background":       "#0d1117",
    "mainBkg":          "#161b22",
    "primaryColor":     "#161b22",
    "primaryTextColor": "#e6edf3",
    "lineColor":        "#00d4ff",
    "git0":             "#00d4ff",
    "git1":             "#4d9fff",
    "git2":             "#79c0ff",
    "gitBranchLabel0":  "#0d1117",
    "gitBranchLabel1":  "#0d1117",
    "gitBranchLabel2":  "#0d1117",
    "gitInv0":          "#0d1117",
    "gitInv1":          "#0d1117",
    "commitLabelColor": "#e6edf3",
    "commitLabelBackground":"#161b22",
    "fontFamily":       "ui-monospace, monospace"
  }
}}%%
gitGraph
    commit
    commit
    branch feature/new-component
    checkout feature/new-component
    commit
    commit
    checkout main
    merge feature/new-component
    commit

How to use it

If you’re using this theme, rendering a diagram is effortless. Simply create a standard Markdown code block and use mermaid as the language tag. You don’t need to import any scripts, upload images, or install any extensions—it renders perfectly on the page out of the box!
